風送式旋轉卸料閥壓力范圍：2kg/cm2系統壓力或壓差。

　　增大入口/出口：正方形，沒有截面尺寸對料流的限 制從而可達高產量。

　　普通型：結構緊湊，占用空間小。

　　軸承外置式：有效的防止粉塵侵入軸承，增大設備適應較高溫度的使用范圍。

　　驅動方式：鏈驅動/馬達直聯驅動。

　　動力配置：擺線針輪減速機、Y系列電機(可按客戶指定動力配置)。

　　材質選項：鈦合金、鋁合金、陶瓷、不銹鋼、碳鋼等。

　　常州同得利機械廠擁有多年的研發生產/定制卸料閥旋轉閥的經驗，秉承質量第 一、用戶至 上的原則。我們的旋轉閥能夠處理鋰電池、鋼廠、電廠、水泥、礦山、環保、塑料、化工、食品和醫藥等行業的各種顆粒、片狀、塊狀物料、粉料、超微粉體等。

　　Pressure range of pneumatic rotary discharge valve: 2kg/cm 2 System pressure or differential pressure.

　　Increase the inlet/outlet: square, with no restrictions on material flow due to cross-sectional size, achieving high production.

　　Normal type: compact structure, occupying small space.

　　External bearing type: effectively prevents dust from entering the bearing, increasing the equipment's adaptability to higher temperature usage range.

　　Drive mode: chain drive/motor direct drive.

　　Power configuration: cycloidal pinwheel reducer, Y-series motor (can be configured according to customer specifications).

　　Material options: titanium alloy, aluminum alloy, ceramic, stainless steel, carbon steel, etc.

　　Changzhou Tongdeli Machinery Factory has many years of experience in research and development, production, and customization of discharge valve rotary valves, adhering to the principle of quality first and customer first. Our rotary valve can handle various types of particles, flakes, blocks, powders, and ultrafine powders in industries such as lithium batteries, steel mills, power plants, cement, mines, environmental protection, plastics, chemicals, food, and pharmaceuticals.
