不銹鋼防卡旋轉閥主要用于塑料、食品、化工、鋰電、礦山、環保行業原料輸送。

　　針對顆粒、片狀、塊狀物料，實現不卡料、不堵料。

　　防卡型旋轉閥主要材質：不銹鋼304-310、鋁合金、鈦合金、陶瓷系列等。

　　壓力：2kg/cm2系統壓力或壓差。

　　增大入口/出口：正方形和圓形。

　　軸承外置式：有效的防止粉塵侵入軸承，增大設備適應較高溫度的使用范圍。

　　驅動方式：鏈驅動/馬達直連驅動口。

　　動力配置：擺線針輪減速機、Y系列電機(可按需方指定動力配置)，排氣口增壓輸送時將葉輪旋轉帶出的高壓氣體通過排氣口送至排氣裝置，提高填充效率。【電話/微信咨詢：陳經理18068546632】

　　旋轉閥氣密封裝置主要用于在氣力輸出系統中，?特別是在需要處理粉塵和小顆粒物料的場合。工作原理依賴于氣體密封技術，?通過保持一定的氣源壓力，?通常高于管道內壓力0.1個大氣壓，?從而在卸料閥內部形成正負壓差，?確保充氣的壓力大于內部物料的壓力，?從而實現有效的密封。?這種設計不僅提高了卸料閥的可靠性，?還能有效防止物料在輸送過程中的泄漏，?確保系統的正常運行。?【電話/微信咨詢：陳經理18068546632】

        《掃二維碼-添加 陳經理 微信-咨詢不銹鋼防卡旋轉閥》

　　Stainless steel anti seize rotary valves are mainly used for raw material transportation in the plastic, food, chemical, lithium battery, mining, and environmental protection industries.

　　For granular, flake, and block materials, achieve no material jamming or blockage.

　　The main materials of anti jamming rotary valve include stainless steel 304-310. aluminum alloy, titanium alloy, ceramic series, etc.

　　Pressure: 2kg/cm 2 system pressure or pressure difference.

　　Increase entrance/exit: square and circular.

　　External bearing: effectively prevents dust from entering the bearing and increases the equipment's adaptability to higher temperatures.

　　Drive mode: chain drive/motor directly connected to the drive port.

　　Power configuration: Cycloid pinwheel reducer, Y-series motor (can be configured according to the power requirements specified by the demand). When the exhaust port is pressurized and transported, the high-pressure gas carried out by the impeller rotation is sent to the exhaust device through the exhaust port to improve the filling efficiency.

　　The rotary valve air seal device is mainly used in pneumatic output systems, especially in situations where dust and small particle materials need to be processed. The working principle relies on gas sealing technology. By maintaining a certain gas source pressure, usually 0.1 atmospheres higher than the pressure inside the pipeline, a positive and negative pressure difference is formed inside the discharge valve to ensure that the inflation pressure is greater than the pressure of the internal material, thus achieving effective sealing. This design not only improves the reliability of the discharge valve, but also effectively prevents material leakage during transportation, ensuring the normal operation of the system.
